Description
- 1/3.2” 2MP PS CMOS Image Sensor (0.7937cm)
- Max. 2MP (1920 × 1080) @25/30fps
- Instastream, H.265 and Smart H.264+ dual-stream encoding
- DWDR, Day/Night (ICR), 3D-DNR, ROI, AWB, AGC, BLC, HLC
- 3.6mm fixed lens
- IR Range of 30 Mtrs, IP67, PoE
- Mobile Software: iCMOB, gCMOB
- CMS Software: KVMS Pro
-
Image Sensor 1/3.2” 2MP PS CMOS Image Sensor (0.7937cm) Minimum Illumination 0.01 lux@F2.0 (Color, 30 IRE) 0.001 lux@F2.0 (B/W,30 IRE) 0 lux (IR on) Effective Pixels 1920(H) x 1080(V) Shutter Speed Auto/Manual, 1/3~1/100000s White Balance Auto; natural; street lamp; outdoor; manual; regional custom Lens 3.6mm Lens Type Fixed-focal Mount Type M12 Max Aperture F2.0 Iris Control Fixed Close Focus Distance 0.8m DORI Distance 55m (Detect) 22m (Observe) 11m (Recognize) 5.5m (Identify) Gain Control (AGC) Auto/Manual Video Compression H.265/Smart H.264+/H.264/ H.264B/ MJPEG (only supported by the sub stream) Encode Strategy Instastream Angle of View H: 79°; V: 43°; D: 94° Back Light Comp. BLC / HLC / DWDR S/N Ratio >56dB Video Streaming Main stream: 1920 × 1080@(1–25/30 fps) Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1– 30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) Mirror Support Motion Detection Off / On (4 area, Rectangle) Privacy Mask 4 areas ICR Auto(ICR)/Color/B/W ROI Support (4 areas) Video Bit Rate H.264: 32 kbps–4096 kbps H.265: 12 kbps–4096 kbp Noise Reduction 3D-DNR Bit Rate Control CBR/VBR Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; Instaon cloud, ONVIF (Profile S; Profile T); CGI Image Rotation 0°/180° Ethernet RJ-45 (10/100Base-T) Alarm Event Network disconnection; IP conflict; illegal access; motion detection; video tampering; security exception Cyber Security Configuration encryption; Trusted execution; Digest; Security logs; HTTPS; Trusted upgrade; WSSE; Trusted boot; Account lockout; Generation and importing of X.509 certification; Video encryption Smart Phone iPhone, iPad, Android Phone User/Host 6 Users (Total bandwidth: 24 Mbps) IR Distance IR Range of 30 Mtr., Smart IR No of IR LEDs 2 (IR LEDs) Browser IE, Chrome, Firefox Edge Storage FTP Operating Temperature 40°C to +50°C (-40 °F to +122 °F) Operating Humidity ≤95% Storage Temperature -40 °C to +60 °C (–40 °F to +140 °F) Storage Humidity ≤95% Power Source DC12V, PoE Power Consumption Basic: 1.2 W (12 VDC); 2.1 W (PoE) Max. (ICR switch+ IR intensity): 2.8 W (12 VDC); 4 W (PoE) Weatherproof Standard IP67 Casing Plastic Dimension 103.2 mm × Φ109.9 mm Weight 0.24kg - Warranty : 2 Years
